Panel fasteners in two or more pieces
Description
PANEL FASTENERS IN TWO OR MORE PIECES
Application
Body
Exterior
Underbody
Dimensions
Use condition dimensions (mm)
F1 - Panel Thickness
0.6 - 6
F2 - Panel Thickness
1 - 3
H - Stud Height
12.75
R - Length of Hole
6.5 - 6.7
Product dimensions (mm)
d - Diameter
18
h - Height
39.1
hb - Height below support
6.5 - 11.9
r1 - Contact Diameter
18
Design
Edge mount
Hole mount
Cavity mount
Round hole
Threaded hole
2 panel thicknesses
Pushing in
Clipping on
